PSI Model 23B Multi-Bag Filter Housing (23 Bag)

The PSI 23-Bag Multi-Bag Filter Housing is the largest-capacity model in our ready-to-ship housing line, engineered for very high flow and bulk liquid filtration. Built entirely from 304 stainless steel, this housing delivers a cost-effective solution for industrial plants requiring reliable throughput and efficient bag changeouts.

Equipped with a bolted lid and secure basket clamps, the unit maintains a consistent seal even under demanding conditions. Its 23-bag configuration provides a flow capacity of up to 4600 GPM at 150 PSI, making it the ideal choice for large-scale systems where maximum productivity and durability are critical.

Key Features

• Material: 304 stainless steel

• Capacity: 23 × #2 size bags (7" × 3")

• Flow Rate: Up to 4600 GPM

• Pressure Rating: 150 PSI

• Connections: 12" ASME flanged inlet/outlet, 2" FNPT drain, ½" FNPT ports, ½" vent

• Construction: Bolted lid with basket clamps; blast surface finish

• Weight: ~2180 lbs

Typical Applications

• Large-scale water and wastewater treatment

• Petrochemical and bulk chemical processing

• Food & beverage production at industrial scale

• Paints, coatings, adhesives, and resins

• High-volume process liquids in manufacturing
