2 Inch Melt Blown Polypropylene Depth Capsule (GDMBXMBP)

Click here for more information

The GDMBX Capsule Filter is a melt-blown polypropylene depth media filter designed for economical prefiltration and particulate removal across a wide range of liquids. Ideal for general service use, GDMBX delivers consistent performance with low extractables and broad chemical compatibility, helping extend the life of downstream filters.

Made using continuous spun bonding technology, GDMBX is an efficient solution for bulk contaminant removal in non-critical applications including water purification, chemical prefiltration, and plating processes.

Key Features:

• Melt-Blown Polypropylene Depth Media: Consistent structure for efficient particulate retention
• Broad Chemical Compatibility: 100% polypropylene construction
• General Service Value: Cost-effective protection for downstream filters
• FDA & EC Compliant: Safe for repeated food contact
• Fiber-Free Effluent: Meets CFR standards for non-fiber releasing filters

Performance Parameters:

• Max Operating Temp (Water): 140 °F at 30 psid (60 °C at 2.07 bar)
• Forward Pressure Limit: 50 psid at 68 °F
• Reverse Pressure Limit: 20 psid at 68 °F
• Recommended Changeout: 35 psid

Sterilization & Cleaning:

• Chemical Sanitization: Compatible with H₂O₂, peracetic acid, bleach, and more

Construction Materials:

• Filtration Media: Melt-blown polypropylene depth media
• Capsule Housing: Polypropylene
• Sealing Method: Thermal bonding
• O-Rings: Buna, Viton® (FKM), EPDM, Silicone, FEP-encapsulated options

Typical Applications:

• Chemicals
• Plating solutions
• Wash solutions
• Potable water
• Water purification
