2 Inch PVDF General Grade GPVWBX Capsule

Click here for more information

The GPVWBX Capsule Filter features a single-layer hydrophobic PVDF membrane engineered for non-aqueous liquids, compressed air, and gas applications. With broad chemical compatibility and high flow capacity, GPVWBX is ideal for critical vent filtration and solvent filtration where moisture resistance is essential.

As part of our general service product line, GPVWBX offers a reliable and economical option for upstream particle reduction or stand-alone use in less critical processes.

Key Features:

• Hydrophobic PVDF Membrane: Designed for air/gas and non-aqueous applications
• Broad Chemical Compatibility: Fluoropolymer construction handles acids, bases, and solvents
• General Service Grade: Effective for prefiltration or standalone use
• FDA & EC Compliant: Meets standards for food-contact safety
• Cost-Effective Protection: Extends life of downstream filters

Performance Parameters:

• Max Operating Temp (Water): 110 °F at 30 psid (43 °C at 2.07 bar)
• Forward Pressure Limit: 80 psid at 68 °F
• Reverse Pressure Limit: 50 psid at 68 °F
• Recommended Changeout: 35 psid

Sterilization & Cleaning:

• Autoclave: 250 °F (121 °C), 30 min, 5+ cycles
• Inline Steam: 275 °F (135 °C), 30 min
• Hot Water: 194 °F (90 °C), 30 min, max 3 psid forward
• Compatible with H₂O₂, peracetic acid, bleach, etc.

Construction Materials:

• Filtration Media: Hydrophobic PVDF membrane
• Support Cage & Housing: Polypropylene
• Sealing Method: Thermal bonding
• O-Rings: Buna, Viton® (FKM), EPDM, Silicone, FEP-encapsulated options

Typical Applications:

• Compressed air
• Non-aqueous solutions
• Solvents
• Tank vents
• Acids & bases
